Motor Not Turning On
If the motor does not turn on when the power switch is in WASH mode, we need to determine whether there is an issue with the power or the components.
The following steps will isolate and identify the issue in the shortest amount of time.
Verify Power
Verify and notate power at the outlet. The machine should be on a dedicated circuit and proper voltage range per the name plate.
Model | Phase | Volts (AC) | Plug (NEMA) |
SM-6450 | 1 | 110-120 | 5-20 |
SM-6455 | 1 | 110-120 | 5-20 |
SM-6650 | 1 | 110-120 | 5-20 |
SM-6690 | 1 | 208-230 | L6-20 |
SM-6695 | 1 | 208-230 | L6-20 |
SM-6795 | 1 | 208-230 | L6-30 |
